Ubiquiti UniFi Dream Wall 17 Port Gigabit 12 Port PoE 2SFP+ WiFi 6 Gateway | UDW

Description

Ubiquiti UDW is a Wall-mountable UniFi Gateway which features 17x Gigabit Ethernet ports with 12x PoE Ports, 1x 2.5Gbps Ethernet Port, 2xSFP+ 10Gbps Ports as well as a built-in WiFi 6 access point and network video recorder. The WiFi 6 delivers an aggregate data rate of up to 2.7Gbps over its 5GHz (4×4 MU-MIMO) and 2.4GHz (2×2 MIMO) bands. It also features a 4.7″ touchscreen for management, 128GB SSD & pre-installed 512GB microSD card and can be configured and managed with the UniFi Network Application.

FEATURES

• Antenna Gain: 2.4GHz: 5.9dBi; 5.8GHz: 6dBi
• Beam-width: 360°
• Data Rate: 2.4GHz: 300Mbps; 5.8GHz: 2400Mbps
• Ethernet Ports: 17x 10/100/1000 ; 1x 10/100/1000/2500
• Hardware Button: Reset
• Max. Power Consumption: 532W
• Mounting: Wall Mount
• Operating System: UniFi
• Operating Temperature: -10°C to 40°C
• PoE Input: None
• PoE Output: 12x PoE Ports (4x 802.3af ; 4x 802.3at ; 4x 802.3bt)
• Power Input: 1x IEC Power Cord (Included)
• Serial Interface: None
• SFP Ports: 1x 10Gbps LAN; 1x 10Gbps WAN
• SIM Slots: None
• Supported Voltage Range: 100-240V
• USB Ports: None
• Other: 1x Micro SD memory card
• Dimensions: 549 x 342 x 62 mm
• Weight: 8.6kg
