Ubiquiti UISP airMAX Loco AC 5GHz 13dBi Radio | LOCO5AC

Description

Ubiquiti’s LOCO-5ACL is an airMAX AC 5GHz radio with a 13dBi antenna. It is designed as a lightweight, cost-effective, short-distance CPE (client premises equipment), PtP (point to point) solution or PtMP (point to multipoint) solution. The dedicated 2.4GHz management radio allows for easy set-up via the UISP network management platform.

*Note: The LOCO-5ACL does not ship with a PoE adapter; we recommend powering the unit with our UPOE-24G12W.

FEATURES

• Antenna Gain: 13dBi
• Beam-width: 45°
• Data Rate: 867Mbps
• Ethernet Ports: 1x 10/100/1000
• Hardware Button: Reset
• Max. Power Consumption: 8.5W
• Mounting: Pole-Mount
• Operating System: airOS
• Operating Temperature: -40°C to 70°C
• PoE Input: 24V Passive PoE
• PoE Output: None
• Power Input: 24V Passive PoE
• Serial Interface: None
• SIM Slots: None
• Supported Voltage Range: 24V
• USB Ports: None
• Dimensions: 179 x 77.5 x 59.1mm
• Weight: 180g

DATA SHEET
